OpenTelemetry: Distributed Traces and Observability in Production

Why OpenTelemetry?

Before OpenTelemetry, every observability tool had its own proprietary SDK: Jaeger SDK, Zipkin SDK, Datadog Agent, New Relic SDK. Instrumenting an application meant choosing a vendor from the start, with tight coupling and prohibitive migration costs. OpenTelemetry (OTel) solves this fundamental problem by providing a single, vendor-neutral SDK that has become the CNCF de-facto standard.

OTel unifies the three observability signals in a single API:

• Traces: end-to-end tracking of a request across multiple services (spans)
• Metrics: counters, gauges, histograms exposed in OTLP or Prometheus format
• Logs: structured logs with automatic correlation to traces via Trace ID

OTel Architecture

The OTel collection chain follows this flow:

Application (OTel SDK)
    │  OTLP gRPC/HTTP
    ▼
OTel Collector (pipeline)
    ├── Receivers  : OTLP, Prometheus, Jaeger, Zipkin, Fluentd
    ├── Processors : batch, memory_limiter, resource, sampling
    └── Exporters  : Tempo (traces), Prometheus (metrics), Loki (logs)
         │
         ├── Grafana Tempo  → Traces
         ├── Prometheus     → Metrics
         └── Grafana Loki   → Logs

Node.js Auto-Instrumentation

OTel provides auto-instrumentation libraries that automatically patch popular modules (Express, HTTP, gRPC, Redis, PostgreSQL) without modifying application code:

// tracing.ts — load BEFORE any other module
import { NodeSDK } from '@opentelemetry/sdk-node';
import { OTLPTraceExporter } from '@opentelemetry/exporter-trace-otlp-grpc';
import { OTLPMetricExporter } from '@opentelemetry/exporter-metrics-otlp-grpc';
import { PeriodicExportingMetricReader } from '@opentelemetry/sdk-metrics';
import { getNodeAutoInstrumentations } from '@opentelemetry/auto-instrumentations-node';
import { Resource } from '@opentelemetry/resources';
import { SemanticResourceAttributes } from '@opentelemetry/semantic-conventions';

const sdk = new NodeSDK({
  resource: new Resource({
    [SemanticResourceAttributes.SERVICE_NAME]: 'payment-service',
    [SemanticResourceAttributes.SERVICE_VERSION]: process.env.APP_VERSION,
    [SemanticResourceAttributes.DEPLOYMENT_ENVIRONMENT]: process.env.NODE_ENV,
  }),
  traceExporter: new OTLPTraceExporter({
    url: 'http://otel-collector:4317',
  }),
  metricReader: new PeriodicExportingMetricReader({
    exporter: new OTLPMetricExporter({ url: 'http://otel-collector:4317' }),
    exportIntervalMillis: 15000,
  }),
  instrumentations: [getNodeAutoInstrumentations()],
});

sdk.start();
process.on('SIGTERM', () => sdk.shutdown());

OTel Collector Configuration

The Collector is the central component that receives, transforms, and exports signals to backends:

# otel-collector-config.yaml
receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317
      http:
        endpoint: 0.0.0.0:4318
  prometheus:
    config:
      scrape_configs:
        - job_name: 'kubernetes-pods'
          kubernetes_sd_configs:
            - role: pod

processors:
  batch:
    timeout: 5s
    send_batch_size: 1024
  memory_limiter:
    limit_mib: 512
    spike_limit_mib: 128
  resource:
    attributes:
      - key: deployment.environment
        value: production
        action: upsert
  tail_sampling:
    decision_wait: 10s
    policies:
      - name: errors-policy
        type: status_code
        status_code: {status_codes: [ERROR]}
      - name: slow-traces
        type: latency
        latency: {threshold_ms: 500}
      - name: probabilistic
        type: probabilistic
        probabilistic: {sampling_percentage: 10}

exporters:
  otlp/tempo:
    endpoint: http://tempo:4317
    tls:
      insecure: true
  prometheusremotewrite:
    endpoint: http://prometheus:9090/api/v1/write
  loki:
    endpoint: http://loki:3100/loki/api/v1/push

service:
  pipelines:
    traces:
      receivers: [otlp]
      processors: [memory_limiter, batch, resource, tail_sampling]
      exporters: [otlp/tempo]
    metrics:
      receivers: [otlp, prometheus]
      processors: [memory_limiter, batch]
      exporters: [prometheusremotewrite]
    logs:
      receivers: [otlp]
      processors: [memory_limiter, batch]
      exporters: [loki]

Grafana Tempo as Trace Backend

Tempo is Grafana Labs' distributed trace backend, designed for massive, low-cost trace storage using S3/GCS as object storage:

# values.yaml for the Tempo Helm chart
tempo:
  storage:
    trace:
      backend: s3
      s3:
        bucket: my-tempo-traces
        region: eu-west-1
        access_key: ${AWS_ACCESS_KEY_ID}
        secret_key: ${AWS_SECRET_ACCESS_KEY}
  retention: 168h   # 7 days

tempoQuery:
  enabled: true

helm repo add grafana https://grafana.github.io/helm-charts
helm upgrade --install tempo grafana/tempo   -f values.yaml   --namespace monitoring

Traces ↔ Logs ↔ Metrics Correlation in Grafana

The power of OTel lies in the automatic correlation of all three signals. In Grafana, configure datasources to enable navigation between signals:

• Trace to Logs: from a Tempo trace, open Loki logs filtered by traceID
• Trace to Metrics: from a trace, view Prometheus metrics for that service at that exact moment
• Exemplars: from a Prometheus metric, jump directly to a representative trace

W3C Trace Context Propagation

For distributed cross-service traces, OTel uses the W3C Trace Context standard (RFC 7230). The traceparent and tracestate headers are automatically propagated by SDKs between HTTP and gRPC services.

Sampling Strategies

• Head-based sampling: decision made at the entry of the trace (before having complete data). Simple, low overhead. Configurable by rate (10 % of traces).
• Tail-based sampling: decision made after the trace ends (access to all data). Allows keeping 100 % of error traces while sampling 5 % of normal traces. Requires more memory in the Collector.

OTel Operator for Kubernetes

The OTel Operator enables auto-instrumentation of applications via a simple Kubernetes annotation, without modifying code or Docker images:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: payment-service
spec:
  template:
    metadata:
      annotations:
        instrumentation.opentelemetry.io/inject-nodejs: "true"
        # Also available: inject-java, inject-python, inject-dotnet
    spec:
      containers:
        - name: app
          image: payment-service:1.0.0

# Instrumentation CRD configuration
apiVersion: opentelemetry.io/v1alpha1
kind: Instrumentation
metadata:
  name: default-instrumentation
  namespace: production
spec:
  exporter:
    endpoint: http://otel-collector:4317
  propagators:
    - tracecontext
    - baggage
  sampler:
    type: parentbased_traceidratio
    argument: "0.1"   # 10 % sampling

Conclusion

OpenTelemetry has solved the vendor lock-in problem in observability. With a single SDK, you can change backends (Datadog to Grafana Stack, or NewRelic to Jaeger) without touching application code. The open-source stack OTel Collector + Grafana Tempo + Prometheus + Loki delivers enterprise-grade observability at controlled cost on Kubernetes.
