GitOps with ArgoCD: Continuous Deployment on Kubernetes

The GitOps Principle

GitOps positions Git as the single source of truth for the desired state of your infrastructure. Every change — deployment, configuration update, scaling — must go through a Pull Request in a Git repository. Operators never connect directly to clusters to make manual changes. ArgoCD continuously monitors the repository and reconciles the cluster's real state with the state declared in Git.

This model delivers considerable benefits: complete auditability (every change is a commit with author and timestamp), trivial rollback (Git revert), multi-environment consistency, and automatic recovery from configuration drift.

Recommended Architecture: Separate Repositories

Best practice separates the application code repository from the Kubernetes configuration repository. This allows independent CI/CD pipelines and avoids mixing deployment logic with business code.

Git Repositories:
  ├── app-source/           # Application code (CI → build → push image)
  └── app-config/           # Kubernetes manifests (GitOps → ArgoCD)
      ├── base/             # Common configuration
      │   ├── deployment.yaml
      │   ├── service.yaml
      │   └── kustomization.yaml
      └── overlays/
          ├── dev/          # Dev overrides (replicas=1, small resources)
          ├── staging/      # Staging overrides
          └── prod/         # Prod overrides (replicas=3, HPA, PDB)

ArgoCD Applications:
  ├── app-dev     → app-config/overlays/dev     (automated sync)
  ├── app-staging → app-config/overlays/staging (automated sync)
  └── app-prod    → app-config/overlays/prod    (MANUAL sync — approval required)

ArgoCD Installation

kubectl create namespace argocd
kubectl apply -n argocd   -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml

# Access the UI
kubectl port-forward svc/argocd-server -n argocd 8080:443

# Retrieve initial admin password
kubectl -n argocd get secret argocd-initial-admin-secret   -o jsonpath="{.data.password}" | base64 -d

Defining an ArgoCD Application (CRD)

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-app-prod
  namespace: argocd
spec:
  project: production
  source:
    repoURL: https://github.com/org/app-config
    targetRevision: HEAD
    path: overlays/prod
  destination:
    server: https://kubernetes.default.svc
    namespace: production
  syncPolicy:
    automated:
      prune: true       # Removes resources deleted from Git
      selfHeal: true    # Reconciles manual changes not in Git
    syncOptions:
      - CreateNamespace=true
      - PrunePropagationPolicy=foreground

CI/CD Pipeline Integration with GitHub Actions

The complete GitOps workflow:

1. Developer pushes to main of app-source repo
2. GitHub Actions builds, tests, and pushes a new Docker image
3. GitHub Actions updates the image tag in app-config
4. ArgoCD detects the commit in app-config and synchronises the cluster

- name: Build and push image
  run: |
    docker build -t $REGISTRY/my-app:${{ github.sha }} .
    docker push $REGISTRY/my-app:${{ github.sha }}

- name: Update image tag in config repo
  run: |
    git clone https://x-access-token:${{ secrets.CONFIG_REPO_TOKEN }}@github.com/org/app-config
    cd app-config
    yq e '.image.tag = "${{ github.sha }}"' -i overlays/prod/values.yaml
    git commit -am "ci: update prod image to ${{ github.sha }}"
    git push

Progressive Deployments with Argo Rollouts

apiVersion: argoproj.io/v1alpha1
kind: Rollout
spec:
  strategy:
    canary:
      steps:
        - setWeight: 10    # 10 % of traffic to new version
        - pause: {duration: 5m}
        - analysis:        # Verify Prometheus metrics
            templates: [{templateName: success-rate}]
        - setWeight: 50
        - pause: {duration: 10m}
        - setWeight: 100
      # Automatic rollback if error rate > 5 %

Conclusion

ArgoCD is the de-facto standard for implementing GitOps on Kubernetes. Its maturity, active community, and integration with the CNCF ecosystem (Argo Rollouts, Argo Workflows, Argo Events) make it a solid production choice. The real gain is not just technical — it is organisational: complete traceability of every deployment, one-command rollbacks, and the elimination of unaudited manual changes on production clusters.
