Why AKS Over a Self-Managed Cluster?
Azure Kubernetes Service delegates control plane management (API server, etcd, scheduler, controller manager) to Microsoft. You only pay for worker nodes — the control plane is free. In return, you get automatic upgrades, a 99.95% SLA on the API server with Availability Zones, and native integration with the Azure ecosystem (Azure AD, Azure Monitor, Azure Container Registry, Azure Load Balancer).
AKS is particularly well-suited to teams that want Kubernetes without the operational overhead of a kubeadm or kops cluster. It is available in all Azure regions, including France Central for data sovereignty requirements.
AKS Reference Architecture
A typical production AKS architecture is built around these components:
- Dedicated VNet with a subnet for nodes and a subnet for pods (Azure CNI)
- System node pool: 3 Standard_D4s_v5 nodes spread across 3 Availability Zones for the application control plane (CoreDNS, konnectivity)
- User node pools: dedicated pools by workload type (general, GPU, spot)
- Azure Container Registry (ACR): attached to the cluster with the AcrPull role on the managed identity
- Azure Key Vault: secrets injected via the CSI driver without going through native Kubernetes secrets
- Azure Application Gateway (AGIC) or NGINX Ingress Controller for HTTP/HTTPS exposure
Networking: Azure CNI vs Kubenet
| Criterion | Azure CNI | Kubenet |
|---|---|---|
| Pod IP | Real VNet IP | Private IP (NAT) |
| IP planning | Critical (1 IP/pod) | Flexible |
| VNet peering | ✅ Native | ⚠️ Manual routes |
| Network Policy | Azure / Calico | Calico only |
| Recommended for | Production | Dev / small clusters |
In production, choose Azure CNI Overlay (available since 2023), which combines Azure CNI advantages without the strict IP planning constraint — pods receive IPs from an overlay address space that is not routed in the VNet.
Identity and Security: Workload Identity
The old AAD Pod Identity approach is deprecated. In 2025, the reference is Azure Workload Identity, based on OIDC federation:
- AKS issues an OIDC token for each ServiceAccount
- An Azure Managed Identity is configured with a federated credential pointing to the AKS OIDC issuer
- The pod mounts the OIDC token via a projected volume
- The Azure SDK automatically exchanges this token for an Azure AD access token
Result: no API keys in Kubernetes secrets, no manual rotation. The pod accesses Key Vault, Blob Storage, or any Azure service with a managed identity.
Auto-Scaling: Cluster Autoscaler and KEDA
- Horizontal Pod Autoscaler (HPA): scales pods based on CPU/memory or custom metrics
- Cluster Autoscaler: adds or removes nodes based on pending pods. Configure
--scale-down-delay-after-add=10mto avoid flapping - KEDA: scales on external metrics — Azure Service Bus queue length, Event Hub message count, Prometheus metrics. KEDA can scale to 0 pods (useful for batch workers)
Monitoring: Azure Monitor + Managed Prometheus
Since 2023, AKS offers Managed Prometheus (Azure Monitor Workspace) and Managed Grafana as an alternative to self-hosting. Activation is a single command, and standard Kubernetes dashboards (Nodes, Pods, Namespaces, API server) are pre-configured. For logs, Container Insights sends stdout/stderr logs to a Log Analytics Workspace with configurable retention.
Updates and Maintenance
- Enable auto-upgrades in
patchmode for automatic security patches - Configure a maintenance window (e.g., Sunday 2–5am) to control when upgrades apply
- Use node image auto-upgrade separately for node OS images (CVE patches without changing the K8s version)
- For minor version upgrades, test first on a staging cluster with the same workload profile
Cost Optimisation
- Reserved Instances on system node pools (3 years = ~55% savings)
- Spot Node Pools for batch workers and dev environments
- Start/Stop cluster: shut down dev clusters outside business hours (~70% savings)
- Enable VPA in "Off" mode (recommendations without auto-action) to identify over-provisioned pods
Conclusion
AKS is a mature Kubernetes service, particularly suited to enterprises already in the Microsoft Azure ecosystem. Its native integration with Azure AD (Workload Identity), Azure Monitor, and IaC tooling (Bicep, Terraform) makes it a solid choice for teams that want Kubernetes without compromising on security and observability.
